What is Dev-C++?
Dev-C++, developed by Bloodshed Software, is a fully featured graphical IDE (Integrated Development Environment), which is able to create Windows or console-based C/C++ programs using the MinGW compiler system. MinGW (Minimalist GNU* for Windows) uses GCC (the GNU g++ compiler collection), which is essentially the same compiler system that is in Cygwin (the unix environment program for Windows) and most versions of Linux. There are, however, differences between Cygwin and MinGW; link to Differences between Cygwin and MinGW for more information.

The atan function returns the arc tangent of a number represented by x. It will return a value between -π/2 and π/2. Required Header. In the C Language, the required header for the atan function is. We use advertisements to support this website and fund the development of new content. Your Movie, Your Theatre There is no dearth of good cinemas in Ahmedabad.And, the theatre in Ahmedabad which has become the hub for cinemagoers is Cinemax: Dev Arc, Ahmedabad.It is the best place to check out all the latest movies in the city. Just make your way to Dev Arc Mall, Near Wide Angle Cinema,Sarkhej Gandhinagar Highway, Opposite Big bazar, Ahmedabad, Gujarat 380055, India. Dev-C is a free full-featured integrated development environment (IDE) distributed under the GNU General Public License for programming in C and C. It is written in Delphi. It is bundled with, and uses, the MinGW or TDM-GCC 64bit port of the GCC as its compiler.

Click picture to enlarge.

Script Hook V Library provides an ability to access script functions from asi plugins. Native Trainer Trainer for GTA V with lots of features. Script research Topic on gtaforums related to the script research. Native database (NATIVE DB). Users have noticed that in some locations of Fallout 4 fps gets low even with a good hardware, mostly it happens in the areas with lots of objects, Shadow Booost plugin is aimed to change that.

Bloodshed!?
I'll be the first to say that the name Bloodshed won't give you warm and fuzzies, but I think it's best if the creator of Bloodshed explains:

First I would like to say that I am not a satanist, that I hate violence/war and that I don't like heavy metal / hard-rock music. I am french, but I do know the meaning of the 'Bloodshed' word, and I use this name because I think it sounds well. If you are offended by the name, I am very sorry but it would be a big mess to change the name now.

You need to use Trigonometry practically like calculating the distance for moving object or angular speed. Arduino provides traditional trigonometric functions (sin, cos, tan, asin, acos, atan) that can be summarized by writing their prototypes. Math.h contains the trigonometry function's prototype. Online arctan(x) calculator. Inverse tangent calculator.Enter the tangent value, select degrees (°) or radians (rad) and press the = button.

There's also a reason why I keep the Bloodshed name. I don't want people to think Bloodshed is a company, because it isn't. I'm just doing this to help people.

Here is a good remark on the Bloodshed name I received from JohnS:
I assumed that this was a reference to the time and effort it requires of you to make these nice software programs, a la 'Blood, Sweat and Tears'.

Peace and freedom,

Colin Laplace

Getting Dev-C++
The author has released Dev-C++ as free software (under GPL) but also offers a CD for purchase which can contain all Bloodshed software (it's customizable), including Dev-C++ with all updates/patches.

Link to Bloodshed Dev-C++ for a list of Dev-C++ download sites.

You should let the installer put Dev-C++ in the default directory of C:Dev-Cpp, as it will make it easier to later install add-ons or upgrades.

Using Dev-C++
This section is probably why you are here.

All programming done for CSCI-2025 will require separate compilation projects (i.e. class header file(s), class implementation file(s) and a main/application/client/driver file). This process is relatively easy as long as you know what Dev-C++ requires to do this. In this page you will be given instructions using the Project menu choice. In another handout you will be given instructions on how to manually compile, link and execute C++ files at the command prompt of a command window. See here.

Step 1: Configure Dev-C++.
We need to modify one of the default settings to allow you to use the debugger with your programs.

  • Go to the 'Tools' menu and select 'Compiler Options'.
  • In the 'Settings' tab, click on 'Linker' in the left panel, and change 'Generate debugging information' to 'Yes':
  • Click 'OK'.

Step 2: Create a new project.
A 'project' can be considered as a container that is used to store all the elements that are required to compile a program.

  • Go to the 'File' menu and select 'New', 'Project...'.
  • Choose 'Empty Project' and make sure 'C++ project' is selected.
    Here you will also give your project a name. You can give your project any valid filename, but keep in mind that the name of your project will also be the name of your final executable.
  • Once you have entered a name for your project, click 'OK'.
  • Dev-C++ will now ask you where to save your project.

Step 3: Create/add source file(s).
You can add empty source files one of two ways:

  • Go to the 'File' menu and select 'New Source File' (or just press CTRL+N) OR
  • Go to the 'Project' menu and select 'New File'.
    Note that Dev-C++ will not ask for a filename for any new source file until you attempt to:
    1. Compile
    2. Save the project
    3. Save the source file
    4. Exit Dev-C++

You can add pre-existing source files one of two ways:
  • Go to the 'Project' menu and select 'Add to Project' OR
  • Right-click on the project name in the left-hand panel and select 'Add to Project'.
EXAMPLE: Multiple source files
In this example, more than 3 files are required to compile the program; The 'driver.cpp' file references 'Deque.h' (which requires 'Deque.cpp') and 'Deque.cpp' references 'Queue.h' (which requires 'Queue.cpp').

Step 4: Compile.
Once you have entered all of your source code, you are ready to compile.

  • Go to the 'Execute' menu and select 'Compile' (or just press CTRL+F9).

    It is likely that you will get some kind of compiler or linker error the first time you attempt to compile a project. Syntax errors will be displayed in the 'Compiler' tab at the bottom of the screen. You can double-click on any error to take you to the place in the source code where it occurred. The 'Linker' tab will flash if there are any linker errors. Linker errors are generally the result of syntax errors not allowing one of the files to compile.

Once your project successfully compiles, the 'Compile Progress' dialog box will have a status of 'Done'. At this point, you may click 'Close'.

Step 5: Execute.
You can now run your program.

  • Go to the 'Execute' menu, choose 'Run'.
Note: to pass command-line parameters to your program, go to the 'Execute' menu, choose 'Parameters' and type in any paramaters you wish to pass.

Disappearing windows
If you execute your program (with or without parameters), you may notice something peculiar; a console window will pop up, flash some text and disappear. The problem is that, if directly executed, console program windows close after the program exits. You can solve this problem one of two ways:

  • Method 1 - Adding one library call:
    On the line before the main's return enter:
    system('Pause');
  • Method 2 - Scaffolding:
    Add the following code before any return statement in main() or any exit() or abort() statement (in any function):
    /* Scaffolding code for testing purposes */
    cin.ignore(256, 'n');
    cout << 'Press ENTER to continue...'<< endl;
    cin.get();
    /* End Scaffolding */
    This will give you a chance to view any output before the program terminates and the window closes.
  • Method 3 - Command-prompt:
    Alternatively, instead of using Dev-C++ to invoke your program, you can just open an MS-DOS Prompt, go to the directory where your program was compiled (i.e. where you saved the project) and enter the program name (along with any parameters). The command-prompt window will not close when the program terminates.

For what it's worth, I use the command-line method.

Step 6: Debug.
When things aren't happening the way you planned, a source-level debugger can be a great tool in determining what really is going on. Dev-C++'s basic debugger functions are controlled via the 'Debug' tab at the bottom of the screen; more advanced functions are available in the 'Debug' menu.

Using the debugger:
The various features of the debugger are pretty obvious. Click the 'Run to cursor' icon to run your program and pause at the current source code cursor location; Click 'Next Step' to step through the code; Click 'Add Watch' to monitor variables.
Setting breakpoints is as easy as clicking in the black space next to the line in the source code.
See the Dev-C++ help topic 'Debugging Your Program' for more information.

Dev-C++ User F.A.Q.

Why do I keep getting errors about 'cout', 'cin', and 'endl' being undeclared?
It has to do with namespaces. You need to add the following line after the includes of your implementation (.cpp) files:

How do I use the C++ string class?
Again, it probably has to do with namespaces. First of all, make sure you '#include <string>' (not string.h). Next, make sure you add 'using namespace std;' after your includes.

Example:

That's it for now.
I am not a Dev-C++ expert by any means (in fact, I do not teach C++ nor use it on a regular basis), but if you have any questions, feel free to email me at jaime@cs.uno.edu

Happy coding!

(Redirected from Dev-Cpp)
Dev-C++
Dev-C++ showing its updated UI and new variable browsing options
Developer(s)Bloodshed Software until 2005, Orwell (Johan Mes) since 2011
Stable release
Repository
Written inDelphi
Operating systemMicrosoft Windows, Linux (alpha only)
TypeIntegrated development environment
LicenseGNU General Public License
Websiteorwelldevcpp.blogspot.com
www.bloodshed.net at the Wayback Machine (archived March 20, 2016)
Usage

Dev-C++ is a free full-featured integrated development environment (IDE) distributed under the GNU General Public License for programming in C and C++. It is written in Delphi.

It is bundled with, and uses, the MinGW or TDM-GCC 64bit port of the GCC as its compiler. Dev-C++ can also be used in combination with Cygwin or any other GCC-based compiler.[1]

Dev-C++ is generally considered a Windows-only program, but there are attempts to create a Linux version: header files and path delimiters are switchable between platforms.

Devpaks[edit]

An additional aspect of Dev-C++ is its use of DevPaks: packaged extensions on the programming environment with additional libraries, templates, and utilities. DevPaks often contain, but are not limited to, GUI utilities, including popular toolkits such as GTK+, wxWidgets, and FLTK. Other DevPaks include libraries for more advanced function use. Users of Dev-C++ can download additional libraries, or packages of code that increase the scope and functionality of Dev-C++, such as graphics, compression, animation, sound support and many more. Users can create Devpaks and host them for free on the site. Also, they are not limited to use with Dev-C++ - the site says 'A typical devpak will work with any MinGW distribution (with any IDE for MinGW)'.

Development status[edit]

From February 22, 2005 to June 2011 the project was not noticeably active, with no news posted nor any updated versions released. In a 2006 forum post, lead developer Colin Laplace stated that he was busy with real-life issues and did not have time to continue development of Dev-C++.[2]

There are two forks of Dev-C++ since then: wxDev-C++ and the Orwell version.

wxDev-C++ is a development team that has taken Dev-C++ and added new features such as support for multiple compilers and a RAD designer for wxWidgets applications.

On June 30, 2011 an unofficial version 4.9.9.3 of Dev-C++ was released by Orwell (Johan Mes), an independent programmer,[3] featuring the more recent GCC 4.5.2 compiler, Windows' SDK resources (Win32 and D3D), numerous bugfixes, and improved stability. On August 27, after five years of officially being in a beta stage, version 5.0 was released.[4] This version also has its own separate SourceForge[5] page since version 5.0.0.5, because the old developer isn't responding to combining requests. On July 2014, Orwell Dev-C++ 5.7.1 was released featuring the more recent GCC 4.8.1 which supports C++11.

Notable uses[edit]

On May 4, 2015, The Singapore Prime Minister Lee Hsien Loong posted his Sudoku solver program in C++ on Facebook. In his screen shot, he's using Microsoft Windows and Dev-C++ as his IDE.[6]
